Little known Factoid.. thecarries at least 4 ALE-70 towed decoys Operationally since Block 2B.
It looks like the USN did put a contract out in April 2014 that has caused some confusion.
BAE Systems Electronic Solutions, Nashua, N.H., is being awarded a $47,352,248 indefinite-delivery/indefinite-quantity delivery order contract for the manufacture of the transmitter countermeasures T-1687A/ALE-70 (V) in support of theprogram. Work will be performed at Nashua, N.H., and work is expected to be completed by April 2017. Fiscal 2014 procurement of ammunition Navy and Marine Corps, and fiscal 2012 Air Force aircraft funding in the amount of $14,314,816 will be obligated at the time of award. The Air Force funds in the amount of $6,308,224 will expire at the end of the current fiscal year. This contract was not competitively procured in accordance with 10 U.S.C. 2304 (c)(l). The NAVSUP Weapon Systems Support, Mechanicsburg, Pa., is the contracting activity (N00104-14-D-K054).
http://archive.defense.gov/Contracts/Contract.aspx?ContractID=5255
These two Budget docs provide a lot of clues... still digging
http://www.dtic.mil/procurement/Y2017/Navy/U_P40_0182_BSA-1_BA-1_APP-1508N_PB_2017.pdf
http://www.dtic.mil/procurement/Y2017/AirForce/U_P40_76_BSA-4_BA-7_APP-3010F_PB_2017.pdf
DESCRIPTION:
The ALE-70 Towed Decoy is a countermeasures dispenser system designed to fit into the () aircraft. The ALE-70 provides aircraft self-protection against radar guided missiles.
Funds procure all system components: decoys, canisters, and explosive cartridges to deploy the decoys.
COUNTERMEASURES: Includes all unique countermeasures that provide self-protection for the() aircraft, specifically ALE-70, MJU-68, MJU-69 and CCU-168. In addition tounique countermeasures, MJU-61 and MJU-64 are also used forself-protection.
ALE-70 = Towed Decoy ($50k each)
MJU-68/69 = Flares http://www.chemring.co.uk/~/media/Files/C/Chemring-V2/PDFs/introduction-to-chemring-for-investors-oct2014.pdf
CCU-168 = Impulse cartridge for the flares https://govtribe.com/project/13-pn-8385852-2-ccu-168b-impulse-cartridge/activity
MJU-61/64 = also flares (4 differenc kinds?)
Absence of chaff info is odd.... But then again, if chaff would decoy the missile then the VLO airframe itself should be good enough, especially with the decoys.
This tidbit from the FY2017 budget (looks like the ALE-70 is in Block 2B/3i already:
(14) ALE-70 FY 2015 quantities increased from PB 2016 to accommodateIOC. FY 2017 quantity change from PB 2016 due to reviseddelivery schedule.
Here are the doors (A=ALE, F = Flares)
garrya over at F-16.net got a hold of a nice hires image
Here is the PDF from BAE that got me started....
http://www.baesystems.com/en-us/download-en-us/20160718215911/1434583878736.pdf
