NACA Langley concept?

[Triton]

NACA Langley airliner concept found on eBay.

Source:

http://www.ebay.com/itm/Air-Liner-Experimental-Cunard-1947-color-PIN-UP-/160870148108?pt=LH_DefaultDomain_0&hash=item25749ba80c



[BAFFLEDBOAR]

Hello Triton, I was wondering if this concept had blueprints, and specifications for range, capacity, etc. I would be highly intrigued if this does have any more info.



[Nik]

Is that smudge at the back just a mark on the print, or a contra-prop to supplement the in-wing jets ??



[martinbayer]

Yep, sure looks like a belt and suspenders approach...



[Jemiba]

Cannot help the feeling, that for this concept, someone put together the tail of the Douglas Skybus, the wing and maybe landing gear of the Martin XB-48, and the fuselage of the Convair XC-99. And especially for the latter, with
its double row of windows, the cockpit looks way to big to me ...



[Nik]

"... the cockpit looks way too big to me ..."

Given the era and engine count, would it have had two flight engineers plus navigator and comms ??
